Description
140DDI35300 Schneider Discrete input module
Modicon 140DDI35300 is part of Modicon’s quantum automation platform. It is a low-voltage DC discrete input module with 32 inputs. It has four sets of channels, each with eight inputs and one positive logic input. The module requires 330 mA of bus current and has 2 input word addressing requirements. It accepts 24 volt DC input and should be used with a shared input common wire connected to a positive potential and for source output devices. It doesn’t have an internal fuse, but users can use an external fuse at their discretion.
Characteristics of the
The number of channels in Modicon 140DDI35300 is 32, with 4 groups and 8 channels in each group. The module is isolated by a group and it uses a receiving logic circuit. 140DDI35300 has two I/O words and is limited by resistance. The required bus current is 330 mA with a power distribution of 1.7 + (number of channels at 0.36x state 1)w. The module is configured online and can be modified online. It is certified by UL 508, CSA 22.2-142, e, FM Class 1 Div. 2 and ATEX zone 2/22. The Modicon 140DDI35300 discrete input module is a interference-free module that is perfectly suited to work in conjunction with quantum security configurations.
The Modicon 140DDI35300 has an input of 24 V c.
advantage
Discrete I/O m module 140DDI35300 allows CCOTF function or dynamic change configuration function. Which cpus support CCOTF functionality? CCOTF functionality is only supported by standalone CPU modules in Unity Pro version 5 or later. Starting with Unity Pro 4.1 or later, hot standby cpus also support CCOTF. Why is CCOTF good? The CCOTF function is useful because it avoids process interruptions. How does that help? This is useful because it helps reduce production costs.
How do I use 140DDI35300
When the 140-DDI-353-00 module is in “On” mode, the voltage should be maintained between 5 and 30 Vdc with a minimum current of 2.0 mA. When off, the voltage reading should be between -3 and 5 Vdc and maintain a maximum current of 0.5 mA. It has a response time of 1 ms between on and off functions, and the 140DDI35300 features troublefree detection. It consumes 1.7 watts, plus 0.36 watts per input in use. The absolute maximum continuous input should be kept below 30 V DC. Its maximum input at 1.3 ms should be a 56 volt DC attenuation pulse. The 140DDI35300 uses a resistance-limited input protection with an internal resistance of 2.5k. The module does not require an external power supply. On its front panel, a total of 32 green leds indicate the status of each dot. The module is standard size and can be easily installed into any Modicon Quantum backplane.
Schneider Electric’s Modicon 140DDI35300 discrete I/O module comes with a two-year warranty.
Product Description
140DDI35300 is a discrete input module manufactured by Schneider Electric – 32I 24 V DC
