Description
140DRA84000 Schneider Discrete output module
The Modicon 140 DRA 84 000 16-point output module was manufactured by Schneider Electric for the Modicon Quantum platform. 140DRA84000 is a relay output 16 x 1 normally open module consisting of standard module format, weighing less than 1 lb and with a bus current requirement of 1,110 mA. It also has a 10 amp, 10 ms surge capability and a 500 volt ampere switching capacity.
The 140 DRA 84 000 relay module does not require external power supply. Power consumption is 5.5W + 0.5W x Input point on. The bus current required for the 140 DRA 84 000 is 1100 mA. I/O mapping :1 output word. The AC operating voltage of Modicon relay module is 20… 250 volts AC voltage, DC operating voltage is 5 volts… 30 volts DC :30… At 150 VDC, the load current decreases.
Features of 140 DRA 84 000
The Modicon 140 DRA 84 000 comes with an LED that displays green while running. When the channels are active, the leds for channels 1 through 16 appear green. Above the LED in front of the 140 DRA 84 000 is the area where you can identify the model number, model description, and model color code. 140 DRA 84 000 Below the LED on the front panel of the relay module is the fuse fuse area. Directly below the fuse fuse area is the field terminal board. The relay common wires 1 to 16 are located in the front left of the module, and the output wires 1 to 16 are located in the front right of the Modicon 140 DRA 84 000 module.
The maximum load current at each point is 2 amps at 250 volts AC, 30 volts DC and 60 degrees Celsius ambient temperature. At a power factor of 0.4 1/8 HP at 125/250 volts AC, a 1 amp tungsten lamp has a load of 1 amp. Maximum load current at each point at 30°… 150 volts DC is equal to 300 MA (resistance load)100 MA (L/R = 10 ms). When t = 10 ms, the maximum load current (surge current) is 10 A capacitive load.
Personal and environmental safety is of Paramount importance when using potentially harmful, dangerous or toxic equipment. With this in mind, the 140 DRA 84 000, as well as the other modules in the series, are available in the conformal coated version, the 140 DRA 84 000C. This relay discrete output module also meets a wide range of required standards for a variety of mechanisms, including:
UL 508
CSA 22.2-142
C-UL
Factory Mutual one, Sector two
Church of England
CSA Level 1, Part 2
The Schneider Electric 140 DRA 84 000 module has C-Tick, GOST and ABS certification.
advantage
Schneider Electric’s Modicon Quantum series of relay discrete output modules are consistently ranked as one of the most environmentally friendly, safe and reliable modules in the industry. As far as the 16-point output module is concerned, this module offers high performance and is one of Schneider Electric’s quality green products, which has been thoroughly evaluated and with people and the environment as its starting point. These green quality products take into account the entire life of discrete output modules to ensure maximum productivity, safety and compliance.
