EGCP-2 8406-121  complete generator control

Features of the 8406-121 include:

  • Engine Control
  • Gen-Set Synchronizing
  • Real (kW) Load Control
  • Reactive (kVAR) Control
  • Automatic Generator Sequencing (multiple units)
  • Gen-Set Protective Features
  • Engine Protective Features
  • Communication – PC Interface (complete details of the communication features may be found online in Communication Manual 26181)
Add to quote
Category:

Description

EGCP-2 8406-121  complete generator control

8406-121 Technical Specifications

Dimensions 282 x 358 x 69 mm
Display Type Two LCD\’s
Features Over/Under Alarm/Shutdown Settings for Oil, Water, and Battery
Input Voltage 50–150 Vac PT input, 9–32 Vdc (SELV), 24V Nominal
Operating Temperature –20 to +70 °C (–4 to +158 °F)
Standards Humidity 95% at 20 to 55 °C (68 to 131 °F)
Storage Temperature –40 to +105 °C (–40 to +221 °F)

Product Description

One of Woodward’s EGCP-2 microprocessor-based complete generator control and engine management

packages, model 8406-121 is used to automate and protect gas or diesel engine-based generator sets.

Features of the 8406-121 include:

  • Engine Control
  • Gen-Set Synchronizing
  • Real (kW) Load Control
  • Reactive (kVAR) Control
  • Automatic Generator Sequencing (multiple units)
  • Gen-Set Protective Features
  • Engine Protective Features
  • Communication – PC Interface (complete details of the communication features may be found online in Communication Manual 26181)

The 8406-121 has an input voltage rating of 150–300 Vac PT Input, 9–32 Vdc, and an operating

temperature rating of –20 to +70 °C. The storage temp rating is –40 to +105 °C. This unit measures

282 x 358 x 69 mm, which includes a front panel with a keypad and two backlit LCD display screens.

The two screens display operating information, status information, and tuning set points. The backlight remains

lit while the engine speed is above 50 rpm. When the engine is not running, the backlight will turn off after 5 minutes

of non-use. It will also turn off in the event of a drop in supply voltage to conserve power. Next to the display

screens is a red LED, used to indicate alarm conditions and shutdown conditions.

Components needed for installation and remote communication are not shipped with the 8406-121 and must be

ordered separately. EGCP-2 Engine Generator Control Package Manual 26174 can be found in our tabs above.
