ZYGO CS1115-801-346 Power and Signal Cable

Key Features

• OEM-fit for ZYGO interferometers – Built to interface the instrument head and controller without pinout guesswork.
• Combined power + signal harness – One routed cable simplifies setup, reduces clutter, and typically improves EMI performance versus mixed leads.
• Low-noise shielding – Helps maintain measurement repeatability by minimizing crosstalk and external interference in sensitive optical signals.
• Secure, keyed connectors – You might notice how the keyed, multi-pin ends reduce mis-mates and speed up swaps during maintenance.
• Bench and rack friendly – Flexible jacket routes cleanly in metrology benches and 19-inch rack enclosures.
• Service-friendly – A straightforward, plug-and-play replacement when troubleshooting power or signal integrity issues.

Technical Specifications

Application Fields

This cable is intended for precision optical metrology setups using ZYGO interferometers. You’ll typically see it in:

• Optics manufacturing and polishing labs (surface form and flatness checks)
• Semiconductor and MEMS metrology benches
• Aerospace/defense optics QA lines
• Calibration rooms and R&D test stations where repeatability is critical

Advantages & Value

• Reliability – OEM-grade termination and shielding reduce downtime caused by intermittent connections.
• Compatibility – Correct pinout and keying for ZYGO systems; no custom rewiring.
• Cost control – A preventative replacement that, in many cases, costs far less than diagnosing sporadic signal issues.
• Support – We help verify fit against your instrument P/N and controller revision before shipping.

Installation & Maintenance

• Environment – Use in a clean, dry lab; follow your interferometer’s grounding and ESD guidelines.
• Routing – Maintain a generous bend radius; avoid tight cable ties. Keep clear of high-power lines and motors to limit EMI.
• Connections – Align keys before mating; hand-tighten any locking collars. Never force the connector.
• Strain relief – Support both ends so the instrument connectors are not load-bearing.
• Care – Periodically inspect for jacket cuts or pin damage; clean connector faces with lint-free swabs and isopropyl alcohol if needed.
• Firmware/Settings – Not required for the cable itself; keep the controller firmware current per ZYGO guidance.

Quality & Certifications

• Manufactured to ZYGO quality standards; suitable for precision optical metrology use
• RoHS-compliant materials; CE conformity applies at system level with the host instrument
• Produced in ISO 9001–controlled environments (typical for ZYGO supply chain)
• Warranty: 365 days

Supporting Components We Can Supply

• CS1115-801 series variants (alternative lengths or keying for specific controller/head pairings)
• Interferometer head–controller harnesses for related ZYGO systems
• Precision metrology accessories: stabilized power leads, cable trays, and strain-relief hardware
