Product details:
The NIMP01 terminal module also works with the INIIT02 infini-net to infini-net transfer module. The INFI-NET to INFI-NET Transmission module (IIT) supports two-way communication through two RS-232-C ports. Port 1 only passes system data. Port 2 can be used to transfer system data or as an interface diagnostic port. Central IIT modules can be used for a variety of means to connect to satellite IIT modules such as modems, microwaves and transceivers. The module communicates directly with the local network interface I/O module connected to the infini-net ring through the I/O extension bus.
INFI-NET to Computer Transmission Module 2 (ICT) provides the operating computer interface for electronic devices needed to guide international networking. It handles all communication with the host computer via the Multifunctional Processor Interface (MPI) or RS-232-C serial port. The MPI interface can act as a DCE or data terminal device. NIMP02 Terminal module Used to terminate redundancy NIMP01 terminal module module
There are two multifunctional processor terminal modules (IMP). The NIMP01 Multifunctional processor terminal module provides an interface to connect to the serial port multifunctional processor 1. NIMP01 terminates
The module has two isolated RS-232-C ports. A port can be configured as a non-isolated RS-485 port. Multifunctional processor modules use ports to communicate with computers, printers and sequential event recorders. The NIMP01 terminal module also provides the station serial connection communication link. The link allows the MFP module to communicate with the IISAC01 analog control station or the NDCS03 digital control station. Figure 1-1 shows the typical application of IMP terminal module.
The NIMP01 terminal module has two configurable jumper RS-232-C interfaces for DCE or DTE operations, either of which can be configured as an RS-485 port. Ports allow MFP modules to talk to a variety of computers and communication devices. When the MFP module connected to the IMP module is the main module and online, the onboard LED lights up. The terminal module provides two serial communication link termination modules for the control station through NICS01 and NIDS01. These links allow MFP modules to communicate with analog and digital control stations. The NIMP02 module has a single LED that lights up the module when redundant MFPS are active.
