SCYC55830 58063282A DC Drive Power Board

Description

Product Description:

SCYC55830 58063282A Technical shortcut

SCYC55830 58063282A Analog inputs

±10 V/±20 mA

• 16 ch., differential, 12 bits + sign resolution, CMV ≤ 50 V,

CMRR > 100 dB (at 50 Hz), (DSAI 130A)

0…+10 V/0…+20 mA

• 32 ch. (DSAI 133A1), single-ended, 12 bits resolution

-100…+320/-200…+640°C

• 31 measuring + 1 reference ch., Pt100, 3-wire, 12 bits + sign

resolution, (DSAI 146)

Thermocouples

• 14 measuring, 2 reference + 1 compensation ch., measuring

ranges B, C, E, J, K, R, S and T with grounded or floating output

signals, 12/13 bits + sign resolution, CMV ≤ 16 V,

CMRR > 100 dB (at 50 Hz), (DSAI 155A)

Analog outputs

±10 V/±20 mA

• 8 ch., 12 bits + sign resolution, galvanically isolated, (DSAO 120A)

0…20 mA

• 16 ch., 12 bits resolution, (DSAO 130A)

Analog inputs/outputs

0…+10 V/0…+20 mA

• 8 input ch., single-ended, 12 bits resolution;
• 8 output ch., 12 bits resolution (DSAX 110A1)

Digital inputs

24 V d.c.

• 32 ch. in 4 groups, optoisolated, read by scanning or interrupts

(DSDI 110AV12/DSTD 190V1,

DSDI 110AV12/DSTD 150A, with screw terminals or

DSDI 110AV12/DSTD 195, galvanic isolated)

Please contact Sunny sales@xiongbagk.cn for the best price.
