1756-L61 Allen-Bradley ControlLogix controller

Description

1756-L61 Allen-Bradley ControlLogix controller

The Allen Bradley 1756-61 is a ControlLogix controller. It features 2MB of user memory and 478 kb of V/O memory, as well as an optional 128 MB of non-volatile storage memory, using a 1784-CF128 CompactFlash memory card. It is a chassis based controller that can be placed in any available slot in the 1756 ControlLogix chassis. Chassis compatible with this controller are 1756-A4, 1756-A7, 1756-A10, 1756-A13, and 1756-A17. It has an open housing and supports up to 250 controller connections. It also has a built-in RS-232 serial communication port. The protocols supported by the RS232 port are DF1 full/half duplex, ASCII, DF1 radio modem, Modbus via logic, and DH-485.
It has a maximum digital /O of 128,000, a maximum analog /O of 4,000, and a maximum total I/0 of 128,000. Controller tasks for the 1756-L61 include 32 tasks, 100 programs each, and Event tasks: all event triggers. The 1756-L61 features various communication options such as ControlNet, Data Highway Plus, EtherNet/P, DeviceNet, SynchLink, Remote VO, and third-party process and device networks. The current consumption of the 1756-L61 controller is 1200 mA at 5.1VDC and 14 mA at 24VDC. Power consumption is 3.5W and heat dissipation is 11.9
BTU/hr. It also has a continuous isolation voltage of 30V and was tested at 720V DC for 60 seconds. It operates at O to 60 degrees Celsius, stores at -40 to 85 degrees Celsius and has a maximum ambient air temperature of 60 degrees Celsius. Relative humidity is between 5% and 95% (non-condensing), vibration is 2g at 10 to 500Hz, and operating and non-operating shocks are 30 and 50 g respectively.
The Allen-Bradley 1756-L61 is a ControlLogix controller with an integrated 2MB user memory that enables the controller to handle up to 128,000 discrete and 4,000 analog V/ OS. The controller features an integrated RS232 communication port and can be logically configured for ASCI, DF1 full/half duplex, DF1 radio modem, DH-485 and Modbus,
The controller supports the implementation of standalone and distributed /O applications. Although the module allows 250 connections. Depending on the communication module used, the network connection may vary. It also supports redundancy to improve system availability, which is often required in critical systems.
The controller also integrates motion, analog input options such as encoder input, LDT input, and SSI input through embedded SERCOS interfaces. If used with an Ethernet communication module, the driver can achieve motion through Ethernet I/P.
Programming languages supported by the controller include relay ladder diagram, structured text, function block diagram (FBD) and sequential function diagram (SFC).
To communicate with the module, an RS232 communication cable is required. Communication suitable for this module is 1756-CP3 or 1747-CP3, right Angle connector to controller, direct to serial port, 3 m (9.84 ft). The module uses batteries to store user programs and data in its memory. For A series A controller, the appropriate battery is 1756-BA1, 1756-BATM, 1756-Bata, and for a Series B controller, the appropriate battery is 1756-BA2.
Within the specified /O capacity, the controller is well suited for most medium-scale processes. To enhance the performance of the modules, you can install additional modules, such as communication modules, professional and intelligent modules, and include partner modules
