Description
1794-IE12 Flex IO High Density Analog Input Module
Technical Specifications for 1794-IE12
Manufacturer | Rockwell Automation |
Product Description: | Flex IO High Density Analog Input Module |
Operating Shock: | 30 g |
Vibration: | 5g @ 10 to 500 Hz |
Storage Temperature: | –40…85 °C (–40…185 °F) |
Operating Temperature: | 0 to 55 C (32 to 131 F) |
Wire Size: | Determined by installed terminal base |
Mounting: | DIN Rail |
External DC supply range: | 10.0…31.2V DC (includes 5% AC ripple) |
External DC supply, nom: | 24V DC |
Indicators: | 1 green/red power/status indicator |
Terminal base: | 1794-TB3G; 1794-TB3GS |
Absolute Accuracy: | 0.1% full scale @ 25 °C |
Resolution: | 16 bit 2’s complement, left justified Voltage: 320 ?V/cnt Current: 0.641 ?A/cnt |
Conversion Type: | Successive Approximation |
Input type: | 0 to 20 mA; 4 to 20 mA; +/- 10VDC; 0 to 10 VDC |
The Allen-Bradley 1794-IE12 is a high-density analog input module from the Flex I/O product family. This module is
primarily used to interface analog devices such as Transmitters, indicators, recorders, single-loop and multi-loop controllers and other devices.
The 1794-IE12 comes with Twelve (12) analog input channels, configurable for 0 to 20mA, 4 to 20 mA, +/- 10VDC and 0 to
10 VDC input signal type. It has an integrated analog to digital conversion circuitry using successive approximation
method with resolution of 320 ?V/cnt for voltage and 0.641 ?A/cnt for current. The analog data format is stored in a 16-bit,
left justified register with 8.0 ms conversion rate on all channels. The absolute accuracy of the 1794-IE12 is 0.1% full
scale @ 25 °C for Voltage and current input with accuracy drift of 0.004% Full Scale/°C.
