3500/22M 288055-01 Bently Nevada Transient Data Interface Module

Description

3500/22M 288055-01 Bently Nevada Transient Data Interface Module

Can be transported to all parts of the world. (Exclude areas that cannot be transported under special circumstances! )

If necessary, please contact customer service.

Xiamen Xiongba Electronic Commerce Co., Ltd. Zhangzhou Branch Main Scope

Products are used in: electric power, petroleum, mine, port, heating, gas, water supply, sewage treatment, metallurgy, paper making, textile, chemical industry, water conservancy and other modern industrial fields!

Purpose: To create excellent quality and excellent service.

Business philosophy: “Honesty and pragmatism” is our constant business philosophy.

Company goal: Our goal is to give you the same product, but the difference is the superior price and attentive service.

Specializing in the world-renowned brand DCS system, robot system, large-scale servo control system and module.

350022M-288055-01

3500 Transient Data Interface (TDI) is the interface between the 3500 monitoring system and Bently Nevada System 1 ™ machinery management software. TDI combines the functions of a 3500/20 frame interface module (RIM) and a communication processor, such as TDXnet. TDI runs in the RIM slot of the 3500 frame and is used in conjunction with M series monitors (3500 / 40M, 3500 / 42M, etc.) to continuously collect steady-state and transient waveform data and transfer the data to the host computer software via Ethernet .

TDI has standard static data collection, but with optional channel-enabled disks, transient or dynamic data can also be collected. Compared with previous communication processors, TDI has several other improvements in addition to integrating the functions of communication processors into the 3500 framework. TDI provides common functions for all the frameworks, but it is not part of the key monitoring channels and does not affect the correct and routine operation of the entire monitoring system. Each frame requires a TDI or RIM.

TDI occupies only one slot in the frame and must be located in the first slot (immediately next to the power module). For triple module redundancy (TMR) applications, the 3500 system requires TDI in the form of TMR. In addition to all standard TDI functions, TMR TDI also has a “monitor channel comparison function”. By selecting the installation function of the monitor option, the 3500TMR configuration performs the monitoring and voting function. In this way, TMR TDI continuously compares the output of three redundant monitors.

If TMR TDI detects that the output information of one of the monitors is not equal to the other two monitors (within the configured percentage), it sends an error indication to the monitor and adds an event to the system event list.
