DS200GDPAG1AKF High frequency power supply board

Ge’s Mark V board DS200GDPAG1AKF is a high-frequency power card. The series of boards is compatible with a range of ge branded drives and exciters. After installation, the drive system can accept AC and DC power supplies. The number of watts this card can produce ranges from 600 to 700 watts. The DC input provided to the board can be between 105 and 140 volts DC in the following grades. The board source AC input can be safely operated at 80 and 132 volts AC. DS200GDPAG1AKF offers a variety of workplace applications. Integrated features include a 50 VAC output transformer, control power supply, and 120 VDC power supply. Both protection and control circuits are on this card. Many onboard features allow input to be captured and sent safely and accurately. These include 27 kHz inverters and regulators as well as input filters and input rectifiers. Each input on the board is isolated, ensuring that some signals do not interfere with other signals on the board. Board status information is presented to the user in a visual manner with two neon signs and four LED indicators found on board.
