IC200PWR012D Versamax isolated power supply

The IC200PWR012 Power Supply is a Versamax isolated power supply designed by GE Fanuc. It is designed

to snap onto the Versamax series of CPUs and network interface units. It has 18 to 30 Volts DC of input voltage,

11 Watts of input power, 20 Amps of inrush current at 24 Volts DC, and 1.5 Amps of total output current. The

IC200PWR012 Power Supply has a compact and modular design with a small footprint. It provides enough flexibility

to match the requirements of the application. It also provides fast processor speed and scalable performance. The

holdup time of this power supply module is 10 milliseconds and the output voltage rating is 5 Volts DC or 3.3 Volts DC.

IC200PWR001G

The IC200PWR012 Power Supply comes with a variety of protective features including short circuit, overload,

and reverse polarity protection. It can also be connected onto a power supply booster carrier. This power supply

module is an extended version of an isolated DC power supply which ensures reliable and powerful operation.

It supports a wide range of communication options and I/O expansion modules. The dimensions of the IC200PWR012

module are 1.95 x 5.25 x 1.54 inches. It provides backplane power to the Versamax CPUs and network

interface units. When it is mounted on a power supply booster carrier, it can be used as a supplemental power supply. This

power supply unit is internally isolated from the frame ground and the +5-Volt and 3.3-Volt outputs

in the power supply. It provides 1500 Volts of isolation between the primary and secondary sides. This module is suitable to

use as the main power source for I/O stations and large I/O applications.
