IC693MDL390 Discrete output module GE

The GE Fanuc IC693MDL340 module is an output module manufactured as part of the GE Intelligent Platform /GE Fanuc Series 90-30 product line. It has a 120 volt AC voltage rating and a 0.5 amp current rating, and provides 16 output points in 2 separate groups with 8 points each, each with a separate common point. The IC693MDL340 module allows each group to be used with an independent phase of the AC power supply. Two common places can also use the same source of power. Each set has a 3 amp fuse for protection, and a RC buffer for output to protect the output from transient electrical noise of the power line.

The GE Fanuc IC693MDL340 module features an AC output voltage range of 85 to 132 volts, a frequency of 50 to 60 Hertz, and a maximum output current of 0.5 amperes per point. Each group allows full speed current of 3 amps per group. The IC693MDL340 module provides high surge current, making the output suitable for controlling different loads, including incandescent and inductive loads. The operator of the module must provide AC power to the module to help its operation connect to the output load. The IC693MDL340 module runs only on AC power. It has LED indicators at the top of the device that show the on and off status of each output point. The leds are arranged in two rows with eight green leds in each row and a red LED in between.
