IC754VSF12CTD Fast panel control and view

Product details:

The IC754VSF12CTD is a fast panel control and view for GE Fanuc Intelligent platform manufacturing

and design under its operator interface product line. GE Fanuc IC754VSF12CTD Quickpanel Controls and

views feature a flat panel display with 16 bits per pixel for a total of 65,536 colors. It has a 12-inch

screen and uses a special mechanism to provide a bright interface screen. The display supports resolution

of 800 x600 pixels; This touch screen allows users to interact with their devices and machines while allowing

them to monitor any processes and progress. GE Fanuc IC754VSF12CTD Quickpanel controls and views

must be mounted on a flat surface with characteristics comparable to NEMA rated panels or enclosures. It is

recommended to allow at least 3 inches of extra space to provide adequate ventilation; If the device is located outdoors, avoid direct sunlight.

It is important that the operating temperature of the module does not exceed the ambient air temperature.

GE Fanuc IC754VSF12CTD Quickpanel controls and views feature touch screen, keyboard, communication

port, CF port, USB port, Ethernet, extension bus, dip switch, and flash. This interface works with Windows; The

CPU has an XScale processor, and the module has a 64 MB flash memory. It also has a memory expansion slot. GE

Fanuc IC754VSF12CTD Quickpanel Controls and views have input voltage of 24 volts DC, actual power of 48 watts and weight of approximately 5.2 lb (2.36 kg).
