Description
Product Overview
The GE IS400TCASH1ADC represents the critical interface nexus within GE’s Mark VIe turbine control system, engineered for high-density signal conditioning and distribution in safety-critical power generation applications. This terminal control assembly (TCA) integrates 64 configurable I/O channels with galvanic isolation, serving as the primary junction between turbine-mounted sensors/actuators and the Mark VIe controller. Designed for extreme environments, the GE IS400TCASH1ADC features MIL-spec connectors and conformal-coated PCBs that withstand salt fog, conductive dust, and rapid thermal cycling (-40°C to +85°C). Its patented “Smart Terminal” technology enables automatic sensor type detection (TC/RTD/mV) while providing ±0.05% signal accuracy – making it indispensable for gas/steam turbine protection systems where measurement integrity prevents catastrophic failures.
## Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS400TCASH1ADC |
| Manufacturer | GE |
| Product Type | Terminal Control Assembly |
| I/O Channels | 64 (individually configurable) |
| Signal Types | TC/J/K/E/T/R/S, RTD, 4-20mA, ±10V |
| Isolation | 1500V AC channel-to-channel |
| Accuracy | ±0.05% FS @ 25°C |
| Max Sampling Rate | 1000 samples/sec (aggregate) |
| Connectors | 4x MIL-DTL-38999 Series III |
| EMC Immunity | 10V/m @ 80MHz-1GHz (IEC 61000-4-3) |
| Shock Resistance | 30g @ 11ms (IEC 60068-2-27) |
| Housing | IP66 aluminum enclosure |
| Weight | 3.2 kg |
| Certifications | SIL 2 (IEC 61508), IEEE 344 (Seismic) |
## Key Features and Advantages
Intelligent Signal Management
Auto-detect circuitry identifies sensor types within 500ms of connection, while continuous lead resistance compensation eliminates measurement errors from cable degradation. The IS400TCASH1ADC’s dual-watchdog design cross-validates signal processing between primary and backup μControllers, ensuring <10ms fault detection.
Extreme Environment Resilience
Gold-plated MIL-spec connectors maintain <5mΩ contact resistance after 500 mating cycles in coal-fired plants. Conformal coating (UL QML-38535) protects against H₂S corrosion in offshore platforms. Internal thermal management maintains ±0.1% accuracy across 125°C temperature gradients.
IS400TCASH1AGD
Maintenance Optimization
Hot-swappable channel modules (replaceable in <2 minutes) minimize turbine downtime. Built-in HART multiplexing allows calibration of 32 transmitters simultaneously without process interruption. QR-coded terminals enable paperless commissioning via ToolboxST Mobile.
Cybersecurity Enforcement
Hardware-enforced IEC 62443 segmentation prevents unauthorized access to critical I/O. Signed firmware updates with TPM 2.0 validation block malware injection. Optical isolation gaps eliminate ground loop vulnerabilities.
## Application Areas
Combined Cycle Power Plants:
12x IS400TCASH1ADC units monitor 768 combustion dynamics probes across 4 gas turbines, detecting flame instability within 5ms to prevent forced outages.
Hydroelectric Governors:
In pumped storage facilities, the assembly’s ±0.01°C RTD accuracy enables precise wicket gate positioning, synchronizing turbine response within 0.02Hz grid frequency deviations.
Offshore Compression:
SIL 2-certified modules control critical shutdown valves on LNG carriers, where IP66 rating and 5g vibration tolerance ensure reliability in North Sea conditions.
Geothermal Steam Fields:
High-temperature version (IS400TCASH1AHC) handles 200°C ambient temperatures while monitoring 64 wellhead pressure/temperature points across sulfuric acid environments.
## Related Products
- IS420ESWBH3A – Ethernet switch (TCA backbone)
- IS415UCVHH1B – Controller module (requires TCA)
- IS410TURPS1A – Redundant power supply
- DS3800HMPA – Memory module (historical data)
- IS400TBAIH1C – Analog input card (expansion)
- IS404TBDOH1D – Digital output card (expansion)
- GAT-4010 – Terminal test adapter
- IS400TCASH1AEC – Explosion-proof variant
- KTC-12 – Conduit sealing kit
- IS400TCASH2A – Successor (supports IO-Link)
