22B-D024N104 Allen-Bradley PowerHlex 40 Series AC drive

Description

22B-D024N104 Allen-Bradley PowerHlex 40 Series AC drive

The Allen-Bradley 22B-D024N104 drive is a PowerHlex 40 series AC drive. The 22B-DO24N104 inverter belongs to the 480-volt AC voltage class and supports input voltages from 342 to 528 volts AC. Transmission inputs are rated at 23.4 kVA and 26 amps. Its output is rated at 24 amps and 15 HP (11 kW). The drive comes without an internal filter, however, it has an internal IGBT brake. The integrated keyboard provided on the converter simplifies the programming process of the converter.
The 4-digit LCD screen of 22B-D024N104 inverter provides users with application information and status updates. The 22B-DO24N104 driver supports control methods including sensorless vector control and voltage per Hertz control. The output frequency can be programmed in the range O to 400 Hz. A typical drive efficiency rating is 97.5%. The 22B-D024N104 drive has a minimum housing volume of 2069 cubic inches. The driver can be mounted on the panel and its housing type is IP 20(NEMA/UL Open) housing. The internal power consumption is 25 watts and the total power consumption is 285 watts. The frame type for the 22B-D024N104 drive is Frame A with dimensions of 320 x 130 x 180 mm. The shipping weight of the hard drives is approximately 9.5 pounds.
The PowerFlex 40, including the 22B-DO24N104, is a sensorless vector controlled drive that delivers high starting torque in the frequency range supported by the drive.
The 228-DO24N104 is an electronic device primarily used to control and regulate the speed of industrial AC motors. In addition, the 22B-DO24N104 can be used to improve the accuracy and efficiency of the control system, enabling multi-point control rather than on/off control of the motor. It also promotes energy savings, as startup, shutdown and even the idle or no-load state of the motor can be parameterized accordingly to reduce energy consumption and save energy.
The 228-DO24N104 operates through a supply voltage range providing 342-528 VAC, 3 phase, 48-63Hz frequency range, and 16.0 amp input current. The adjustable frequency AC driver operates the motor by providing an output voltage range of 0-460VAC, a three-phase continuous current of 24.0 amps, and a frequency range of 0-40OHz. The driver is suitable for 11.0 kW or 15.0 HP motor ratings.
It comes with a fixed keyboard and integrated lGBT brakes. The drive supports enhanced functionality as it can be installed with a remote mount or Remote Handheld Human-machine interface module (HIM). Frequency drives can also be installed with additional communication adapters for Profibus, BACnet, LonWorks, Ethernet /P, DeviceNet, and ControlNet communication protocols. The embedded communication port of the 22B-DO24N104 is an RS485 communication port that allows converters to connect to a Daisy chain network, in which a maximum of 32 converters can be connected to one network segment.
