The AC 700F controller comes in a really small footprint and high signal density of S700 I/O. The S700 I/O modules are directly plugged to the CPU module or can be used as remote I/O via PROFIBUS. A maximum of eight modules can be connected to one controller. 3rd party I/O‘s can be connected via Details
G3 compliant components are protected with a special coating against corrosive gases. The following Freelance ISA71.04 G3 compliant components can be ordered under the same conditions as any ordinary Freelance component. G3 compliance for AC 800F requires exclusively use of –Z components. AM 810F-Z serves for closing unused slots and the behind system plug. G3 Details
FF / HSE module FI 840F FI 840F 3BDH000033R1 Fieldbus Module, FF HSE. Freelance V7.1SP2a or higher is mandatory. The FI 840F is a high speed ethernet fieldbus module designed for fast data exchange in production engineering with decentralized peripherals. The FF / HSE module FI 840F is a Fieldbus Foundation-(FF)-Master. Using the Freelance it Details
AM 811F 3BDH000050R1 Battery Module To use together with PM 803F Without battery SB 808. Freelance V7.1SP2a or higher is mandatory. The battery module can be used in non-redundant controllers with only one Ethernet module to increases the buffering time. Features: • Provides battery backup • Enables redundant battery energy backup on the AC 800F Details
FI 830F PROFIBUS module FI 830F 3BDH000032R1 Fieldbus Module, PROFIBUS-DP To use together with PM 802F or PM 803F. The FI 830F module interfaces to the PROFIBUS fieldbus. It provides functionality according to the PROFIBUS-DP V1 standard (DIN 19245 amendment 1) and supports baud rates up 12 MBd. The module is the master on the Details
Serial module FI 820F FI 820F3BDH000031R1 Fieldbus Module, Serial (2 channel) To use together with PM 802F or PM 803F. The FI 820F module provides connectivity to a variety of serial fieldbuses and serial protocols. Standard protocol is MODBUS By using different connection cables the physical nterface can easily be selected: RS485 (half duplex), RS422 Details
CAN-3 module FI 810 FI 810F 3BDH000030R1 Fieldbus Module, 3 channel CAN modules. To use together with PM 802F or PM 803F for rack I/O. The FI 810F module provides connectivity to the Freelance rack I/O - up to 5 racks can be connected. It provides functionality according CAN 2.0 specification and supports baud rates Details
EI 813F 3BDH000022R1 Ethernet Module 10BaseT (Twisted pair) To use together with PM 802F or PM 803F. Battery not included. Freelance V7.1SP2a or higher is mandatory. These communication modules provide Ethernet communications to the control network compliant with IEEE802.3 standard.Communications module, compliant with 10 BaseT shielded Twisted Pair (STP, cable category 3, 4 or 5 Details
SD 812F 3BDH000014R1 Power Supply 24 VDC To use together with PM 802F or PM 803F. Freelance V7.1SP2a or higher is mandatory. The AC 800F modules are supplied with 5 VDC / 5.5 A and 3.3 VDC / 6.5 A by SD 812F. The power supply has open-circuit, overload and sustained short-circuit protection. The electronically Details
SA 811F 3BDH000013R1 Power Supply 115 / 230 VAC To use together with PM 802F or PM 803F. Freelance V7.1SP2a or higher is mandatory. The AC 800F modules are supplied with 5 VDC / 5.5 A and 3.3 VDC / 6.5 A by SA 811F. The power supply has open-circuit, overload and sustaine short-circuit protection. Details
