News

Motorola MVME147 Serie

The MVME147 was tested in an FCC-compliant chassis, and meets the requirements for Class A equipment. FCC compliance was achieved under the following conditions: 1. Shielded cables on all external I/O ports. 2. Cable shields connected to earth ground via metal shell connectors bonded to a conductive module front panel. 3. Conductive chassis rails connected
Details

Motorola MVME 141 Serie

Features: Single-Slot VME Module MC68030 32-Bit Microprocessor Reset / Abort Control Functions Front Panel LED Status Indication The Emerson / Motorola MVME141 Single Board Computer is a single slot VME Module with a MC68030 32-bit 33.3 MHz Micoprocessor. This SBC has front panel LED status indication and Reset / Abort control functions. Configuration: • Processor:
Details

Motorola MVME135 Series

MVME135/136 is a high-performance MC68020 microprocessor module based on the VME double-height, single-width form factor. MVME135/136 contains MC6802032 address and data microprocessor advanced multiprocessor CSR and fast DRAM of IMB or 4MB. Other key features provided include Demand Paged Memory Management Unit (PMMU), FioatingPoint Coprocessor (FPCP), and interfaces to VMEbus and VSBbus. The MVME135/136 is
Details

Motorola MVME134 Series

Emerson / Motorola MVME134 32-Bit Monoboard Microcomputer Configuration: • 16.67 MHz MC68020 Processor • 4 MB DRAM Memory • 2 KB SRAM Memory Part Number: 01-W3471B B02B Features: 4MB of Shared Local DRAM (3) 8-Bit Programmable Timers for Tick and Watchdog Functions MC68020 Microprocessor with 32-Bit Address and 16.67MHz (20.00MHz for MVME134FP) MC68851 Paged Memory
Details

Motorola MVME133 series

The MVME133 is specified, designed and tested to operate reliably over an intake air temperature range of 0C to 55C with forced air cooling at speeds typically achievable by a 71CFM axial fan. Temperature qualification is performed in a standard Motorola VME Systems chassis. Twenty-five watt load boards were inserted into two card slots, one
Details

Vibro-meter VM600 IOC4T input/output card for MPC4 cards

VM600 IOC4T input/output card for MPC4 cards Input/output (interface) card for an MPC4 or MPC4SIL card – supports 4 dynamic channels and 2 tachometer channels Differential signal input with sensor power supply output per dynamic channel and per tachometer channel Differential buffered (raw) transducer output per dynamic channel DC output configurable as current-based signal (4
Details

Vibro-meter VM600 CPUR2 rack controller and communications interface card

VM600 CPUR2 rack controller and communications interface card VM600 CPUR2/IOCR2 rack controller and communications interface card pair with support for Modbus TCP and PROFIBUS DP “One-Shot” configuration management of protection cards (MPC4) in a VM600 rack using an Ethernet connection to a computer running the VM600 MPSx and VibroSight® software Mathematical processing of data to
Details

Vibro-meter VM600 CPUR rack controller and communications interface card

VM600 CPUR rack controller and communications interface card VM600 CPUR/IOCR rack controller and communications interface card pair with support for Modbus RTU/TCP and card pair redundancy “One-Shot” configuration management of protection cards (MPC4 and AMC8) in a VM600 rack using an Ethernet connection to a computer running the VM600 MPSx and VibroSight® software Rack controller
Details

Vibro-meter VM600 CPUM modular CPU card

VM600 CPUM modular CPU card VM600 CPUM/IOCN rack controller and communications interface card pair with support for Modbus RTU/TCP or PROFINET, and a front-panel display “One-Shot” configuration management of protection cards (MPC4 and AMC8) in a VM600 rack using an Ethernet or RS-232 serial connection to a computer running the VM600 MPSx software Front-panel display
Details
